NO.

Project name

Project content

Quantity

1

Power supply system category

Central power control equipment single-phase AC 220V

1 set

2

Power wiring category

Voltage regulator 220V overload protection circuit

1 set

Single-phase and AC mobile cable reel, with 4 cores and 6 square cables, about 30 meters long, with leakage protection.

1 set

The whole vehicle 220V circuit system line with other electricity split control (Nanyang national standard line)

1 set

Distribution of national standard sheath wires around the body, inside the interior panel of the car (Nanyang national standard wires)

About 20 meters

Switched outlets 10-15A,2-eye,3-eye

3-4

Lighting: Ultra-thin LED long strip lighting

4

Wire assemblies (fireproof, corrosion resistant)

1 set

3

Electrical system

Distribution box and distribution system (Customized)

1 set

UV sterilizing light (After stopping the car, you can push the green switch for power and then red switch for start work. The light will work in 1 min, and stop 30 min later automatically.)

1

4

Doctor's console

Customized, PVC sheet, with storage cabinet below.

1 sheet

5

Movable, fixed work chairs

Pneumatic Adjustable Doctor's Chair/Assistant Chair

2-3 sheets

6

Cabinet seat for 2-persons

With comfort back, soft seat cushion and 2 sets of seat belts, with storage underneath the seat cushion.

2 sheets

7

Hanging cabinets

The left and right side of the hanging cabinets divided into 2 compartments, the cabinet door using semi-transparent injection molding parts, the use of curved design, the volume is larger, the hinge for any stop design form, the operation of the convenience and safety. Hanging cabinets are made of ABS material with overall mold injection molding.

2 sets

8

Mark

All kinds of warning signs and labels inside and outside the vehicle

1 set

9

Pad pasting

Film pasting on both side windows and rear window of vehicle.

1 set

10

Interior floor

Medical cabin floor: wear-resistant, acid-resistant, alkali-resistant, flame-retardant, anti-slip, mildew-proof, easy-to-clean medical plastic floor; It meets the requirements of GB8410-2006 "Combustion characteristics of automotive interior materials".

1 set

11

Overhead air conditioner

Well-known brand, when working in the car: 1-d2P cold and warm energy-saving duct air conditioning, cold and warm air everywhere in the whole car, each air outlet can adjust the air output

When driving: with the car's own cold and warm air conditioning, ≥ 14,000 calories, double air ducts,4kw

1 set

12

Others

Designed according to the user's requirements, can be cloth network cable and network port, increase the wireless LAN configuration.

1 set

Roof vent

1

Surrounding curtain

1

Clean water tank

1

Waste water tank

1

water channel

1

water pump

1

Instant water heater

1

Warm air blower

1

Coat hook

1

2KG fire extinguisher

1

1 medical garbage can, 1 household garbage can

1

13

Dental equipments

Dental operating chair

1

Conveying system

1

Inhalation device

1

Dental Suspension Tower

1

Sterilizer

1

Portable X-ray machine

1
